Weighing in at only 3 grams, this is an excellent option for your smaller FPV quadcopter video system.
CLICK HERE for the Turnigy LT250 transmitter with clover for this camera.
CLICK HERE for the Diatone adjustable mount for this camera (4 colors available)
Description:
Resolution: 1280 * 960
Resolution: 600TVL
Camera Dimensions: 12.5mm * 12.5mm * 17mm
Illumination: 0.5LUX
Format: NTSC
Power supply range: 3.7-5V ONLY
Audio Lens: Wide-angle 1.8mm (170 degree)
Image sensor:1/4 CMOS image sensor
Sensitive area: 3.5964mm x 2.7084mm
648 pixels (horizontal) × 488 (vertical) 648 (horizontal) × 488 (vertical)
Scanning Frequency Horizontal: 15.625KHz
Vertical: 50Hz
level: 15.7343KHz
Vertical: 60Hz
Electronic Shutter 1 / 50-1 / 80000 (sec) 1 / 60-1 / 80000 (sec)
SNR ≥48dB (AGC OFF)
Minimum illumination : 0.1 Lux / F1.2
Composite video signal :1.0Vp-p 75Ω
Standard Lens :1.8 mm
Specifications PCB: 20mm*20mm
Power: DC5V ± 10% 70mA ± 10%
Operating temperature :-10 ℃ ~ 60 ℃ RH95% Max
Package included:
1 x 600TVL Wide Angle Lens Camera
